Types and specifications

Rods, bars and wires

ASTM B574, B166, B425, B473, B408, B805, B164, B865, B446

Plates, sheets and strips

ASTM A240, A480, B575, B168, B906, B424, B463, B409, B872, B127, B443, B637

Seamless pipes/tubes

ASTM B622, B167, B829, B423, B729, B407, B983, B165, B444

Welded pipes

ASTM B619, B775, B517, B775, B705, B464, B514, B725

Welded tubes

ASTM B626, B751, B516, B704, B468, B515, B730

Bw fittings

ASTM B366

Forgings

ASTM B564

Material grades

Hastelloy series

Hastelloy C-276(N10276, 2.4819), Hastelloy N(N10003), Hastelloy B/B-2/3(N10001/N10665/N10675), Hastelloy C-4/C-22/C-2000/G-30/G-35(N06455/N06022 /N06200/N06030/N06035, 2.4610/2.4602/2.4675/2.4603/2.4643)

Inconel series

Inconel 600(N06600, 2.4816), Inconel 601(N06601, 2.4851), Inconel 617(N06617, 2.4663A), Inconel 625(N06625, 2.4856), Inconel 718(N07718, 2.4668), Inconel X750(N07750, 2.4669)

Incoloy series

Incoloy A-286(S66286, 1.4980), Incoloy 020(N08020), Incoloy 800(N08800, 1.4876), Incoloy 800H(N08810, 1.4958), Incoloy 800HT(N08811, 1.4959), Incoloy 825(N08825, 2.4858), Incoloy 925(N09925)

Monel series

Monel 400(N04400, 2.4360, 2.4361), Monel 401(N04401), Monel 404(N04404, 2.4867), Monel K-500(N05500, 2.4375)

Remarks

Hastelloy is a registered trademark of Haynes International Inc.

Inconel, Incoloy and Monel are registered trademarks of the Special Metals Corporation Group of Companies.

Types and specifications

Rods, bars and wires

ASTM B160

GB/T 4435

Plates, sheets and strips

ASTM B162, B906

GB/T 2072, GB/T 2054

Seamless pipes/tubes

ASTM B161, B163, B829

GB/T 2882

Welded pipes/tubes

ASTM B725, B775, B730, B751

Bw fittings

ASTM B366

Material grades

ASTM Nickel 200(N02200), Nickel 201(N02201)

DIN 2.4060/2.4066, 2.4061/2.4068

GB N4, N5, N6, N7

Range of Sizes

Seamless pipes/tubes

OD 10~159mm, WT 0.5~20mm

Plates, sheets and strips

Thickness 0.3~50mm, Width<2500mm, Length<6000mm

Types and specifications

Rods, bars and wires

ASTM B348

GB/T 2965, Q/B S2331

Plates sheets and strips

ASTM B265, F67, AMS 4911

GB/T 3621, GB/T 14845

Seamless pipes/tubes

ASTM B337, B338, B861, AMS 4942/4945/4944/4943

GB/T 3624, GB/T 3625

DIN 17861

Welded pipes/tubes

ASTM B338, B862

Bw fittings

ASTM B363, ANSI B16.9

EN 10253-4

HG/T 3651, GB/T 12459, GB/T 13401

Flanges

ASTM B381, ANSI B16.5

EN 1092-1

HG 20592~20605, GB/T 9112~9124

Material grades

ASTM Gr. 1, Gr. 2, Gr. 3, Gr. 5, Gr. 7, Gr. 12

GB TA1, TA2, TA3, TA5, TA6, TA7, TA9, TA10, TB2, TC1, TC2, TC3, TC4, TC6, TC9, TC10, TC11, TC12

Range of Sizes

Seamless pipes/tubes

Diameter 5~168mm, Thickness 0.5~20mm

Welded pipes

Diameter 76~630mm, Thickness 3.0~10mm

Length<6000mm with no circumferential welding seam

Bw fittings

DN15~DN1200(1/2"~48")

WT 2.5~22mm

Plates, sheets and strips

Thickness 0.5~80mm, Width<2500mm, Length<6000mm
